Full bottom view.  Note the rubber feet, even though the unit is fairly heavy, the feet were needed to prevent it from creeping along the bench.  The star knobs are the clamps for the work surface adjustment.  A second HD clamp has been added, this is a very secure mounting.  Not shown in any of the pictures is the bolt that is under the die grinder that holds the grinder mount into the main body.  The ends of the mount are cut at 45° and were left sharp from the milling operation to make it grip the housing better.
